CCRQ Optics Co.,Ltd
$40-80 /Piece/Pieces
| Τρόπος Πληρωμής: | T/T |
| Incoterm: | FOB |
| Min. Παραγγελία: | 10 Piece/Pieces |
| μεταφορά: | Express,Air |
| Λιμάνι: | Beijing,Guangzhou,Shenzhen |
Σκιά:
Αρ. μοντέλου: DM-CCRQ
| Πώληση μονάδων | : | Piece/Pieces |
| Τύπος Πακέτου | : | τυλιγμένο με φούσκα σε κουτί για να αποφευχθεί η ζημιά |
| Παράδειγμα εικόνας | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
| K9 glass mirror | Fused silica mirror |
| Borosilicate optical glss with additives | high-purity silicon dioxide amorphous( glass state) |
|
Low cost and extremely high value for money, excellent optical uniformity
easy to process and polish
|
the coefficient of thermal expansion extremely thermal staibility is outstanding, the laser damage threshold is extremely high,
the light transmission range cover deep ultraviolet to near infrared excellent chemical stability and corrosion resistance
|
| coefficient of thermal expansion high, and it is prone to deformation when heated, which caused distortion of the wavefront laser damage threshold is relatively low Absoption occurs in the ultraviolet and infrared wavelength ranges | the price is very high,usually serveral to serval dozen times that of k9 hardness is high,making the processing and polishing more difficult and time-consuming |
|
Low and medium power laser such as He-Ne laser for teaching purposes<500w
optical systems that are insensitive to thermal effects cost sensitive prototype development or mass produced consumer products
|
High power laser( fiber lasers, soild-state lasers with power ranging from serval hundred watts to kilowatts ultrafast lasers( femtosecond/picosecond lasers) are sensive to dipersion and thermal lensing effects ultraviolet or deep infrared applications interferometers and astronomical instruments that have extremely high requirements for thermal stability and wavefront fidelity |
| Substrate | K9, fused silica |
| Size | 5-300mm |
| thickness | 3-10mm |
| Type | Dielectric HR Coating |
| Center wavelength | 532nm, 633nm, 1064nm |
| AOI | 0° or 45° |
| Reflectivity | >99.9% |
| S/D | 20/20 |
| Surface Flatness | λ/10 |
